Incredibly Durable FDA 2mm Spot Mould Laser Welding Machine With 2 Lamps

Name: Incredibly Durable FDA 2mm Spot Mould Laser Welding Machine With 2 Lamps
Brand: Purple Horn
Price: 1 USD

Wholesale Incredibly Durable FDA 2mm Spot Mould Laser Welding Machine With 2 Lamps from china suppliers

Brand Name : Purple Horn

Model Number : ML-WY-M02-400W

Certification : CE, FDA

Place of Origin : China

MOQ : 1 SET

Price : Negotiable

Payment Terms : T/T, Western Union

Supply Ability : 200 sets/month

Delivery Time : 10-15 days

Packaging Details : Wooden case package: 1680*500*1500mm/560kg

Power Supply : 380VAC ± 10% / 50-60HZ

Output power : 400W

Dimension : 1000mm x 600mm x 1500mm

Net weight : 560kg

Laser source : YAG laser

Welding wire : 0.1-0.8mm

Laser Type : Pulse

Spot size range : 0.2-2mm

Contact Now

Incredibly Durable Mould Laser Welding Machine Mold Repair Laser Welders

Product introduction:

Welding on large size precision injection, die-casting, mould repairing, patch welding on sand hole or air hole in beryllium copper mould insert, aluminum casting, copper casting, welding or patch welding processing for large size products.

Features:

It adopted Ceramic condenser cavity, high reflectivity, strong power, and extremely long service life.
It had high power laser device with 2 lamps, which meets the welding processing needs of the copper, aluminum and those moulds and products requires lot of welding works.
The heavy duty bearing for the worktable is provided the ability to load with heavy jobs, and meanwhile it remain the advantages of light and flexible at the same time.
It is equipped with 3P high power integration design cooling water system, which ensured the stability of high power welding.

Product parameters:

Model	ML-WY-M02
Average laser power	400W
Max energy of single pulse	75J
Laser wavelength	1064nm
Pulse width	0-20ms
Laser welding frequency	0.5 -100HZ
Spot size range	0.2-2mm
Welding wire	0.1-0.8mm
Power Supply	380VAC ± 10% / 50-60HZ
Power Consumption	12 KW
Water pressure protection	≤ 0.025MPa
Cooling water temperature	≤ 35 degrees
Temperature protection	45 degrees
Cooling water flow	10L/min
Dimensional	1000mm x 600mm x 1500mm
Weight	560kg
Cooling Way	Water cooling
Laser Type	Pulse
Hazard Class	4 Class

Main parts of machine:

Samples for reference:

FAQ

1. How is the payment?

30% deposit before production and the balance 70% before shipment

2. How is the delivery and shipment?

Ship in 7 days after 100% payment;
Plywood box packaging

3. How will you guarantee aftersales services?

We offer two warranty for laser source, one year for whole machine and lifetime maintenance services.
Engineers available to service machinery overseas
Free technical training in our factory
Free sample can be sent to you
Professional technical team 24 hours online

4. How about your presales service?

Speeding offer within 8 hours quick response and free consulting.
Free sample welding or testing is available
Progressing solution design to all clients, including distributors and end users.
